Best practices for hardening a Cardano mining pool

June 18, 2021

4 min

I was asked to come up with and advice regarding hardening a Cardano mining pool. As this is a bit out of my comfort zone I decided to document my journey and do some research into best practices. It might help others and I am very open to discussions about some of the choices and for other practices that can be utilized to keep it as secure as possible.

Note: Running the cardano pool on a kubernetes cluster, with enough resources, could also work; but for this blog I assume an architecture consisting out of several VPS servers to keep the complexity as low as possible for the time being.

After reading a bit in the docs a mining pool seems te consist out of a couple of high available servers that will run the cardano-node software + an offline/airgapped server + one or more relay nodes. So at least 4 servers that need to be configured and maintained. The relay nodes seem to be quite essential in providing and extra layer of security.

Relay nodes do not have any keys, so they cannot produce blocks. Instead, relays act as proxies between the core network nodes and the internet, establishing a security perimeter around the core, block-producing network nodes. Since external nodes cannot communicate with block-producing nodes directly, relay nodes ensure that the integrity of the core nodes and the blockchain remains intact, even if one or more relays become compromised.

Security hardening for Cardano stake pools is not merely about simply following a guide once and you are done with it. Security hardening is one of the pool operators main tasks in order to achieve a solid uptime.

Organisational countermeasures and rules

With fully hardened and updated servers there can be other threats, like social engineering, weak passwords, key logging, rootkits, malware, ransom etc. To mitigate these kinds of risks a vision + a set of security rules are needed.

Use 2FA everywhere, preferably without SMS (Google Authenticator or Yubikey)
Run some sort of malware/ransomware scan
No re-used passwords in the context of the pool
No secrets, passes or creds in git hub repo’s
A formal on and off-boarding protocol for admins
Ransomware proof backup
No single point of failure in the members of the admin group

As a stake pool involves managing a couple of servers with almost the same specs I would advise to use some sort of provisioning tools. Ansible would be really good for managing the ubuntu deps and general config needs of the servers. That also makes it easy do stuff on all the nodes or to quickly deploy an extra relay or block producing node.

Hardening the servers itself

Linux is well-known for being one of the most secure operating systems available. But that doesn’t mean you can count on it to be as secure as possible right out of the box. There are a some quick, easy steps you can take to ensure your platform is even more secure.

Secure Shared Memory

One of the first things you should do is secure the shared memory used on the system. If you’re unaware, shared memory can be used in an attack against a running service. Because of this, secure that portion of system memory. You can do this by modifying the /etc/fstab file.

Add the following line to the bottom of that file:

For the changes to take effect, reboot the server.

Although SSH is fairly secure by default, you can make it more secure by enabling SSH login only for specific users and / or by only allowing it from known IP’s. You can do this by modifying /etc/ssh/sshd_config. Add the allowed users at the bottom.

You can wild card stuff here so, to allow all users in 192.168.1.0/24 access:

Adding a security login banner might not seem like the most effective security measure, it has benefits. For example, if an unwanted user gains access to your server, and if they see that you included specific information in a login banner (warning them of the consequences of their actions), they might think twice about continuing.

Edit /etc/issue.net to your likings. Now disable the MOTD by editing: /etc/pam.d/sshd

Comment the 2 lines:

Uncomment this line in /etc/ssh/sshd_config:

Restart SSHD to inspect the changes:

Restrict SU Access

Unless configured otherwise, Linux users can use the su command to change to a different user. When they do that, they gain the privileges granted to that other user. So if user A (who has limited access to the server) uses su to change to user B (who has less limited access to the server), user A is now user B and can do more to the server. Because of this, disable access to the su command.

Create a new group:

Add users to this group, for example, to add user admin to the group. The command for this is:

Grant access to su for the added group:

Make brute password attempts hard

You could install fail2ban or a set of firewall rules to ensure that multiple attempts with wrong passwords or SSH keys get you blocked permanently or for a while.

You can add this to an ansible playbook to load a firewall that blocks SSH access after a couple of wrong attempts:

DOS and DDOS mitigation

Firewalling:

the firewall on the block-producing node’s servers should be configured to only allow incoming connections from its relays. If a relay node becomes compromised, you can simply switch it off and use a different one.
Todo: Investigate if dynamic protocols are used; e.g. can other outgoing traffic that not originates from the pool and protocols itself be blocked?
Probably good to add some sort of software firewalling in addition to a hardware firewall if possible

On the servers with internet administrators use ssh accessible CLI tools for operations on the pool.

Here my journey ends for now. Did I forget stuff? Probably. Feel free to comment.

Update November 2021: I’ve fiddled around with Ansible and can now automate most of the tasks in the cluster. Including upgrading the node. If there is need for such docs from the Cardano community I would be happy to write a blog post on that. I found quite some abandoned Ansible attempts so it might be not the best tool for the job. I am also interested in experiences with running it on kubernetes. Happy mining. 🚀

Reading material used:

Stake operator best practices

Official stake pool course

For fun: hardening-cardano-against-quantum-computers

Hardening ubuntu 18.04

Practical hardening guide (CentOS)

Terrafrom template for HA cardano setup on AWS
